| PART NUMBER |
REVRESE STAND-OFF VOLTAGE |
BREAKDOWN VOLTAGE V BR (V) Min.@IT |
BREAKDOWN VOLTAGE V BR (V) Max.@IT |
TEST CURRENT |
MAXIMUM CLAMPING VOLTAGE @IPP |
PEAKIMUM CURRENT@ 8*20us wave from |
REVERSE LEAKAGE@ VRWM |
PDF下载 |
| BI-POLAR | VRWM(V) | VBR min(V) | VBR max(V) | IT(mA) | Vc(V) | Ipp(A) | IR(μ)A |  |
| AK10-058C | 58.0 | 64.0 | 70.0 | 10 | 110.0 | 10000 | 10 | |
| AK10-076C | 76.0 | 85.5 | 94.5 | 10 | 140.0 | 10000 | 10 | |
| AK10-170C | 170.0 | 189.7 | 210.0 | 10 | 160.0 | 10000 | 10 | |
| AK10-190C | 190.0 | 200.0 | 245.0 | 10 | 190.0 | 10000 | 10 | |
| AK10-220C | 220.0 | 230.0 | 270.0 | 10 | 330.0 | 10000 | 10 | |
| AK10-240C | 240.0 | 254.1 | 280.8 | 10 | 340.0 | 10000 | 10 | |
| AK10-250C | 250.0 | 263.2 | 290.9 | 10 | 413.0 | 10000 | 10 | |
| AK10-380C | 380.0 | 401.0 | 443.0 | 10 | 520.0 | 10000 | 10 | |
| AK10-430C | 430.0 | 440.0 | 490.0 | 10 | 625.0 | 10000 | 10 | |
| AK10-530C | 530.0 | 559.0 | 618.0 | 10 | 725.0 | 10000 | 10 | |
 |
